Display:

• Panel Size: 65"
• Panel Type: TFT LCD Module with DLED Backlight.
• Display Area (mm): 1428.48mm(H) x 803.52mm(V) (64.5")
• Aspect Ratio: 16:9
• Resolution: UHD 3840x2160
• Colors: 1.07B colors
• Brightness: 400 nits (typ.)
• Contrast Ratio: 1200:1 (typ.) / 5000:1 (DCR)
• Response Time: 6.5 ms
• Viewing Angles: H = 178, V = 178 typ.
• Backlight Life: 50,000 Hours (Min)
• Surface Treatment: Hardness:9H, AG+AF
• Orientation: Landscape

Platform:

• Processor: Octa-Core CPU
• RAM: 16GB
• Storage: 128GB

Touch:

• Type/ Tech: Ultra Fine Touch Techology (IR Recognition)
• Touch Resolution: 32767 x 32767
• Touch Point: EDLA/Android/Windows: 50 points of touch
• Palm Rejection: Yes

INPUT:

• HDMI: x4 (Frontx2:HDMI2.1 with CEC,HDCP ; Rearx2: [(HDMI2.1 with CEC, HDCP)x1+(HDMI2.1 with CEC, HDCP, ARC)x1]
• RGB / VGA: x1
• DisplayPort: x1
• Audio: x1
• RS232: x1
• SD/SDHC: TF Card Slot(Micro SD)
• OPS: x1 PC Slot

OUTPUT:

• HDMI: x1 (HDMI 2.1, HDCP 1.x)
• Audio: x1 (Line out)
• SPDIF: x1 (optical)

LAN:

• RJ45: x2

USB:

• Type A: x5 (Front x2 and Rear x 2 with USB3.2 Gen 1, all support SmartPort USB ; Rear x 1 with USB 2.0 for system update)
• Type B: x2 (Front x 1 and Rear x 1 with USB3.2 Gen 1)
• Type C: x3 (Frontx1 with USB3.2 Gen 1, DP1.2, Ethernet 100M, PD 65W; Rearx1 with USB3.2 Gen 1, DP1.2, Ethernet 100M, PD 15W; Topx1 with USB3.2 Gen 1, PD 15W)

Speakers:

• 25W x 2 front soundbar + 20W x 1 subwoofer

Microphone:

• Built-in 8-array microphone

Top Camera Plate:

• Yes

Compatibility:

• RGB PC/HDMI PC: 1920x1080 @ 60Hz
• HDMI: 3840x2160
• DisplayPort: 3840x2160

Embedded OS:

• EDLA-Certified with Android 14

Bundled Software:

• Basic Annotation Software: myViewBoard for Android
• Pro Annotation Software: myViewBoard for Windows (embedded in VPC)
• Wireless Presentation: AirSync
• Device Management: Manager
• ViewSonic Launcher: Yes

Special Features:

• All-in-one USB port: USB 3.2 Gen 1 “SmartPort USB” to all channels
• Simple LAN sharing between IFP and slot-in device: 10/100/1000M (USB Type-C 10/100, Android & PC 10/100/1000)
• Light Sensor: Yes
• NFC Reader: Yes
• Pen Sensor for supporting Write Away: Yes

Power:

• Voltage: 100-240V AC +/- 10% Wide Range
• Consumption: On:76.16W; Off:<0.5W

Ergonomics:

• Wall Mount (VESA® ): 400 x 200

Operating Conditions:

• Temperature (º C): 0°C to 40°C
• Humidity: 20% ~ 80% RH non-condensing

Dimensions:

• Physical (inch / mm): 58.6 x 35.99 x 3.36 in / 1488.4 x 914.2 x 85.3 mm
• Packaging (inch / mm): 64.09 x 40.16 x 7.28 in / 1628 x 1020 x 185 mm

Weight:

• Net (lb / kg): 76.15 lb / 34.54 kg
• Gross (lb / kg): 93.28 lb / 42.31 kg

Regulations:

• cTUVus, FCC/ICES003, Energy Star 8.0, EMC/CE, CB/LVD, GOST-R/EAC, UkrSEPRO, EPEAT, Mexico NOM , Mexico Energy, UKCA, UK-EEL, BSMI, BIS, LBL( Low Blue Light Certification), Flicker Free, Green BOM, RoHS, ErP-Eco, REACH, SCIP, WEEE, TPCH , Packing waste, CA65, PAIA

Energy Star version:

• 8.0

Package Contents:

• 1. Power Cord x1 3 meters,
• 2. USB Type-C cable x1 1.8 meters, USB-IF certified
• 3. USB Touch cable x1 3 meters
• 4. Touch pen (Passive pen) x 2
• 5. Quick Start Guide
• 6. RS232 adapter x1
• 7. Clamp x 5
• 8. Camera Plate x1
• 9. Screw x 8 (camera 2+2, wall mount 4)
• 10. HDMI cable x1 3meters,
• (HDMI LA certified)
• 11. Remote controller x1
• 12 AAA battery x2
• 13. Compliance statement
• 14. Warranty card (only for VSCN)
• ‍

Compatible Slot-in PC:

• VPCF5-W33-G1,
• VPC37-W53-G1,
• VPC35-W53-G1,
• VPC-A31-O1
